Building a Design System with Tailwind and Radix

A design system isn't just components—it's constraints that enable consistency and speed. Combining Tailwind's utility-first approach with Radix's accessible primitives creates a powerful foundation.

Design Tokens: The Foundation

// tailwind.config.ts
export default {
  theme: {
    extend: {
      colors: {
        brand: {
          50: '#faf5ff',
          500: '#8b5cf6',
          900: '#4c1d95',
        },
        semantic: {
          success: '#22c55e',
          warning: '#f59e0b',
          error: '#ef4444',
        },
      },
      spacing: {
        'component-xs': '0.25rem',
        'component-sm': '0.5rem',
        'component-md': '1rem',
        'component-lg': '1.5rem',
      },
      borderRadius: {
        'component': '0.5rem',
      },
    },
  },
}

Component Architecture with Radix

// components/ui/button.tsx
import * as React from 'react'
import { Slot } from '@radix-ui/react-slot'
import { cva, type VariantProps } from 'class-variance-authority'
import { cn } from '@/lib/utils'

const buttonVariants = cva(
  'inline-flex items-center justify-center rounded-component font-medium transition-colors focus-visible:outline-none focus-visible:ring-2 disabled:pointer-events-none disabled:opacity-50',
  {
    variants: {
      variant: {
        primary: 'bg-brand-500 text-white hover:bg-brand-600',
        secondary: 'bg-gray-100 text-gray-900 hover:bg-gray-200',
        ghost: 'hover:bg-gray-100',
        destructive: 'bg-semantic-error text-white hover:bg-red-600',
      },
      size: {
        sm: 'h-8 px-3 text-sm',
        md: 'h-10 px-4',
        lg: 'h-12 px-6 text-lg',
      },
    },
    defaultVariants: {
      variant: 'primary',
      size: 'md',
    },
  }
)

interface ButtonProps extends React.ButtonHTMLAttributes,
  VariantProps {
  asChild?: boolean
}

const Button = React.forwardRef(
  ({ className, variant, size, asChild = false, ...props }, ref) => {
    const Comp = asChild ? Slot : 'button'
    return (

    )
  }
)

export { Button, buttonVariants }

Accessible Primitives with Radix

// Dialog with full accessibility
import * as Dialog from '@radix-ui/react-dialog'

export function Modal({ trigger, title, children }) {
  return (

      {trigger}



          {title}
          {children}


              ×





  )
}

Documentation with Storybook

// Button.stories.tsx
import type { Meta, StoryObj } from '@storybook/react'
import { Button } from './button'

const meta: Meta = {
  component: Button,
  tags: ['autodocs'],
  argTypes: {
    variant: {
      control: 'select',
      options: ['primary', 'secondary', 'ghost', 'destructive'],
    },
    size: {
      control: 'select',
      options: ['sm', 'md', 'lg'],
    },
  },
}

export default meta
type Story = StoryObj

export const Primary: Story = {
  args: { children: 'Primary Button', variant: 'primary' },
}

export const AllVariants: Story = {
  render: () => (


      Primary
      Secondary
      Ghost
      Destructive

  ),
}

Key Takeaways

Design tokens establish the visual language. Colors, spacing, and typography should be systematic.

CVA manages variant complexity. Class Variance Authority makes multi-variant components maintainable.

Radix provides accessibility for free. Focus management, keyboard navigation, and ARIA are built in.

Documentation is part of the system. Storybook ensures components are discoverable and usable.
