API Rate Limiting: Protecting Your Backend

Without rate limiting, one aggressive client can bring down your entire service. But implementation is trickier than it sounds—distributed systems, user fairness, and graceful degradation all matter.

Rate Limiting Algorithms

// 1. Token Bucket - smooth, allows bursts
class TokenBucket {
  private tokens: number
  private lastRefill: number

  constructor(
    private capacity: number,      // Max tokens
    private refillRate: number     // Tokens per second
  ) {
    this.tokens = capacity
    this.lastRefill = Date.now()
  }

  tryConsume(tokens: number = 1): boolean {
    this.refill()
    if (this.tokens >= tokens) {
      this.tokens -= tokens
      return true
    }
    return false
  }

  private refill() {
    const now = Date.now()
    const elapsed = (now - this.lastRefill) / 1000
    this.tokens = Math.min(this.capacity, this.tokens + elapsed * this.refillRate)
    this.lastRefill = now
  }
}

// 2. Sliding Window - more accurate, more complex
class SlidingWindowCounter {
  constructor(
    private windowSize: number,  // In milliseconds
    private limit: number
  ) {}

  async checkLimit(key: string, redis: Redis): Promise {
    const now = Date.now()
    const windowStart = now - this.windowSize

    // Remove old entries and count current window
    await redis.zremrangebyscore(key, 0, windowStart)
    const count = await redis.zcard(key)

    if (count < this.limit) {
      await redis.zadd(key, now, `${now}-${Math.random()}`)
      await redis.pexpire(key, this.windowSize)
      return true
    }
    return false
  }
}

Distributed Rate Limiting with Redis

import { Redis } from 'ioredis'

class DistributedRateLimiter {
  constructor(private redis: Redis) {}

  async checkRateLimit(config: RateLimitConfig): Promise {
    const key = `ratelimit:${config.identifier}`
    const now = Date.now()
    const windowStart = now - config.windowMs

    // Lua script for atomic operation
    const script = `
      local key = KEYS[1]
      local now = tonumber(ARGV[1])
      local window = tonumber(ARGV[2])
      local limit = tonumber(ARGV[3])

      -- Remove old entries
      redis.call('ZREMRANGEBYSCORE', key, 0, now - window)

      -- Count current entries
      local count = redis.call('ZCARD', key)

      if count < limit then
        -- Add new entry
        redis.call('ZADD', key, now, now .. '-' .. math.random())
        redis.call('PEXPIRE', key, window)
        return {1, limit - count - 1, 0}  -- allowed, remaining, retry-after
      else
        -- Get oldest entry for retry-after
        local oldest = redis.call('ZRANGE', key, 0, 0, 'WITHSCORES')
        local retryAfter = oldest[2] and (oldest[2] + window - now) or window
        return {0, 0, retryAfter}  -- denied, remaining, retry-after
      end
    `

    const [allowed, remaining, retryAfter] = await this.redis.eval(
      script, 1, key, now, config.windowMs, config.limit
    )

    return {
      allowed: allowed === 1,
      remaining,
      retryAfterMs: retryAfter,
    }
  }
}

Per-User vs Per-IP vs Per-API-Key

function getRateLimitIdentifier(request: Request): RateLimitIdentifier {
  // API key takes precedence (authenticated users)
  const apiKey = request.headers.get('x-api-key')
  if (apiKey) {
    return { type: 'api-key', value: apiKey, limit: 1000 }  // Higher limit
  }

  // Authenticated user
  const userId = request.auth?.userId
  if (userId) {
    return { type: 'user', value: userId, limit: 100 }
  }

  // Fall back to IP (lowest trust)
  const ip = request.headers.get('x-forwarded-for')?.split(',')[0] ||
             request.headers.get('x-real-ip') ||
             'unknown'
  return { type: 'ip', value: ip, limit: 20 }
}

Graceful Degradation: 429 Handling

function createRateLimitResponse(result: RateLimitResult): Response {
  const headers = {
    'X-RateLimit-Limit': result.limit.toString(),
    'X-RateLimit-Remaining': result.remaining.toString(),
    'X-RateLimit-Reset': new Date(Date.now() + result.retryAfterMs).toISOString(),
  }

  if (!result.allowed) {
    return new Response(
      JSON.stringify({
        error: 'Too Many Requests',
        message: 'Rate limit exceeded. Please retry later.',
        retryAfter: Math.ceil(result.retryAfterMs / 1000),
      }),
      {
        status: 429,
        headers: {
          ...headers,
          'Retry-After': Math.ceil(result.retryAfterMs / 1000).toString(),
        },
      }
    )
  }

  return null  // Continue with request
}

Rate Limit Headers for Clients

// Client-side rate limit handling
async function fetchWithRateLimit(url: string, options?: RequestInit) {
  const response = await fetch(url, options)

  const remaining = parseInt(response.headers.get('X-RateLimit-Remaining') || '0')
  const reset = response.headers.get('X-RateLimit-Reset')

  if (response.status === 429) {
    const retryAfter = parseInt(response.headers.get('Retry-After') || '60')
    await new Promise(resolve => setTimeout(resolve, retryAfter * 1000))
    return fetchWithRateLimit(url, options)  // Retry
  }

  // Proactive slowdown when approaching limit
  if (remaining < 10) {
    await new Promise(resolve => setTimeout(resolve, 100))
  }

  return response
}

Key Takeaways

Use Redis for distributed systems. In-memory rate limiting doesn't work across servers.

Choose the right algorithm. Token bucket allows bursts; sliding window is more accurate.

Communicate limits clearly. Headers help clients back off gracefully.

Tier your limits. Authenticated users get more than anonymous IPs.
